Transparent quartz plate or Quartz ring and Curved glass window

  • Transparent quartz plate or Quartz ring and Curved glass window
  • Transparent quartz plate or Quartz ring and Curved glass window
  • Transparent quartz plate or Quartz ring and Curved glass window
Place of Origin China
Brand Name WZ
Certification CE
Model Number CY09
Minimum Order Quantity 2 pcs
Price US$6.0-80.0/pc
Packaging Details carton case with foam
Delivery Time 6 -10 days
Payment Terms T/T, Western Union
Supply Ability 4000pcs/month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Application Lab Using Shape Round Shape,curved Plate ,rectangle
Dimensions Customized Chemical Composition Quartz Glass
Product Name Quartz Glass Plate
Leave a Message
Product Description

clear fused silica quartz disc,optical JGS2 quartz plate
1. high purity >99.9%
2. high transmission
3. high temperature resistant.

High Temperature Resistant Clear and Polished Quartz Glass Plate

clear fused silica quartz disc
silica quartz price
Product Description

High Temperature Clear Quartz Glass Plate

Chemical composition (unit:ppm)

Al Fe K Na Li Ca Mg Cu Mn Pb B Ti
20 1.0 3.5 3.5 1.0 2.0 0.5 0.3 0.5 <0.01 <0.2 2.0

Physical Properties:

Density 20°CKg X m-3(X 103) 2.2
Coefficient of expansion 25-300°C°C-1(X 10-6) 0.56
Softening point(°C) 1710
Annealing point(°C) 1230
Strain point(°C) 1140
Youngs modulus(Pa) 7.5X105


1. Material properties
High Corrosion Resistance
Broad Transmission Spectrum
Low Thermal Expansion Coefficient
Both side polished
Can work long time with 1100° C
2. Use:
Wieldy used in medical, electronic instrument, scientific research, optical industry etc.
3. Shape:
round, square, rectangular and various shapes are available.

Size and thickness:


 Transparent quartz plate or Quartz ring and Curved glass window 0
